After completing this chapter, you will be able to:
A DC motor is like a spinning top powered by a battery – it converts electrical energy into rotational motion. When you adjust how much power you give it (using a technique called PWM, which is like flickering a light switch very fast), the motor spins faster or slower. You will find DC motors in everyday things like fans, toy cars, and water pumps.
DC motors provide continuous rotational motion, controlled by voltage and PWM for speed regulation.
Characteristics:
Think of an H-bridge like a railway switch that can reverse a train’s direction. A DC motor spins one way when current flows left-to-right, and the opposite way when current flows right-to-left.
The H-Bridge Layout: Four switches (transistors) arranged in an “H” shape around the motor. By activating diagonal pairs, you control direction:
Why you need it: Your microcontroller can’t directly reverse polarity on a motor. The H-bridge does this electronically without physically swapping wires. Combined with PWM on the enable pin, you get full speed + direction control from just 3 GPIO pins.
PWM (Pulse Width Modulation) is the standard method for controlling DC motor speed:
Why use PWM? Digital microcontrollers can’t produce true analog voltages. Instead, they rapidly switch between 0V and 5V. A motor responds to the average voltage over time, creating smooth control without complex analog circuits.
A 75% PWM duty cycle on a 12V motor delivers \(V_{avg} = 0.75 \times 12 = 9\) V average. If the motor draws 400mA at this speed, power is \(P = V \times I = 9 \times 0.4 = 3.6\) W. Compare this to a linear voltage regulator dropping 12V to 9V: the regulator would dissipate \((12-9) \times 0.4 = 1.2\) W as heat (25% wasted), while the PWM MOSFET switch wastes only \(\approx 0.1\) W in switching losses (<3%). Over 8 hours of operation, PWM saves \((1.2 - 0.1) \times 8 = 8.8\) Wh compared to linear control.
Interactive PWM Efficiency Calculator:
Option A: Low PWM frequency (1 kHz): Minimal switching losses (<1% power loss), audible motor whine at 1kHz, coarse current ripple causing motor heating, suitable for high-inertia loads (fans, pumps), driver efficiency 95-98%
Option B: High PWM frequency (20 kHz): Switching losses increase to 3-5%, inaudible operation (above human hearing), smooth current with reduced ripple/heating, required for precision positioning (servos, gimbals), driver efficiency 90-95%
Decision Factors: For consumer products (smart blinds, HVAC dampers), use 20kHz to eliminate audible noise complaints. For industrial pumps where noise is acceptable and efficiency matters, use 1-5kHz. Stepper motors typically use 1-2kHz to maintain torque at steps.
Choosing the wrong motor driver is the most common hardware mistake in student IoT projects. Use this 3-step process:
Step 1: Determine motor current requirements
| Motor Type | Typical Current | Stall Current | Minimum Driver Rating |
|---|---|---|---|
| Small hobby motor (3-6V) | 100-300 mA | 500-800 mA | 1A per channel |
| N20 gear motor (6-12V) | 200-500 mA | 1-2 A | 2A per channel |
| 775 motor (12-24V) | 1-3 A | 5-10 A | 15A per channel |
| Windshield wiper motor (12V) | 3-8 A | 15-25 A | 30A per channel |
Step 2: Match driver to current and features needed
| Driver | Current Rating | Voltage | Cost | Best For |
|---|---|---|---|---|
| L293D | 600 mA (1.2A peak) | 4.5-36V | $1.50 | Small hobby motors only |
| L298N | 2A per channel | 5-35V | $2.50 | N20 gear motors, educational projects |
| TB6612FNG | 1.2A (3.2A peak) | 2.5-13.5V | $3.00 | Efficient small motors, battery projects |
| BTS7960 | 43A per channel | 5.5-27V | $8.00 | 775 motors, high-current applications |
| DRV8871 | 3.6A continuous | 6.5-45V | $4.50 | Single motor, industrial grade |
Step 3: Check thermal limits
The L298N has a total voltage drop of 2-4V across its internal Darlington transistors (both high-side and low-side combined). At 2A, this dissipates 4-8W of heat. The TB6612FNG uses MOSFETs with much lower resistance and has only ~0.5V total drop, dissipating 1W at the same current.
Worked example: Smart pet feeder with 12V N20 gear motor (400 mA continuous, 1.5A stall)
Common mistake: Using an L298N with a 6V rated motor and 7.4V LiPo battery, expecting full motor performance. The L298N’s ~2V total drop means the motor actually gets 5.4V (27% below its 7.4V supply). The TB6612FNG would deliver 6.9V (only 7% loss).
The L298N is a popular dual H-bridge driver capable of controlling two DC motors or one stepper motor. This example demonstrates basic speed and direction control, showing how PWM duty cycle maps to motor speed.
// L298N H-Bridge Motor Driver — ESP32
#define MOTOR_IN1 26
#define MOTOR_IN2 27
#define MOTOR_EN 14 // PWM pin
const int pwmChannel = 0;
void setup() {
Serial.begin(115200);
pinMode(MOTOR_IN1, OUTPUT);
pinMode(MOTOR_IN2, OUTPUT);
ledcSetup(pwmChannel, 5000, 8); // 5 kHz, 8-bit (0-255)
ledcAttachPin(MOTOR_EN, pwmChannel);
}
void loop() {
motorControl(150, true); // Forward at ~60% speed
delay(2000);
motorControl(0, true); // Stop
delay(1000);
motorControl(191, false); // Backward at ~75% speed
delay(2000);
// Gradual acceleration and deceleration
for (int speed = 0; speed <= 255; speed += 5) {
motorControl(speed, true);
delay(50);
}
for (int speed = 255; speed >= 0; speed -= 5) {
motorControl(speed, true);
delay(50);
}
delay(1000);
}
void motorControl(int speed, bool forward) {
speed = constrain(speed, 0, 255);
// Set direction via IN1/IN2, then set speed via PWM
digitalWrite(MOTOR_IN1, forward ? HIGH : LOW);
digitalWrite(MOTOR_IN2, forward ? LOW : HIGH);
ledcWrite(pwmChannel, speed);
}
void motorBrake() {
// Short brake: both inputs HIGH shorts motor terminals
digitalWrite(MOTOR_IN1, HIGH);
digitalWrite(MOTOR_IN2, HIGH);
ledcWrite(pwmChannel, 255);
}
void motorCoast() {
// Coast: both inputs LOW, motor spins freely to stop
digitalWrite(MOTOR_IN1, LOW);
digitalWrite(MOTOR_IN2, LOW);
ledcWrite(pwmChannel, 0);
}For precise speed control, use a PID (Proportional-Integral-Derivative) controller with encoder feedback. This example builds on the L298N motor driver code shown earlier.
#include <PID_v1.h>
// Uses motorControl() from the L298N example above
#define ENCODER_A 32
#define ENCODER_B 33
volatile long encoderCount = 0;
unsigned long lastTime = 0;
// PID variables — tune Kp/Ki/Kd for your motor
double setpoint = 100.0, input, output; // Target: 100 RPM
PID motorPID(&input, &output, &setpoint, 2.0, 5.0, 1.0, DIRECT);
void setup() {
Serial.begin(115200);
// Motor setup (same as L298N example above)
pinMode(ENCODER_A, INPUT_PULLUP);
pinMode(ENCODER_B, INPUT_PULLUP);
attachInterrupt(digitalPinToInterrupt(ENCODER_A), encoderISR, RISING);
motorPID.SetMode(AUTOMATIC);
motorPID.SetOutputLimits(0, 255);
motorPID.SetSampleTime(100); // Compute every 100ms
}
void loop() {
unsigned long now = millis();
if (now - lastTime >= 100) {
// RPM = (pulses * 60s * 1000ms) / (PPR * elapsed_ms)
float currentRPM = (encoderCount * 60000.0) / (20.0 * (now - lastTime));
encoderCount = 0;
lastTime = now;
input = currentRPM;
motorPID.Compute();
motorControl((int)output, true); // Apply PID output
Serial.printf("Target: %.0f RPM | Current: %.1f RPM | PWM: %.0f\n",
setpoint, currentRPM, output);
}
}
void encoderISR() {
encoderCount += (digitalRead(ENCODER_B) == HIGH) ? 1 : -1;
}Scenario: You want a cooling fan that runs at half speed when your ESP32 detects 25°C, and full speed above 30°C.
Setup: TT motor fan (3-6V), powered from 5V through an L298N driver.
Code:
if (temperature < 25) {
motorControl(0, true); // Fan OFF
} else if (temperature < 30) {
motorControl(128, true); // Half speed (128/255 = 50%)
} else {
motorControl(255, true); // Full speed (255/255 = 100%)
}Why it works: PWM value 128 out of 255 gives 50% duty cycle = average 2.5V delivered to the motor = half speed. The motor sees the average voltage over many rapid on/off cycles.
Scenario: Prevent voltage drops and current spikes by ramping motor speed gradually.
Problem: Instant full-speed startup draws 5-8× running current, causing brownouts on battery systems.
Solution:
void softStart(int targetSpeed, int rampTime) {
if (targetSpeed <= 0) return; // Safety check
int steps = targetSpeed / 5; // Number of 5-unit steps
if (steps == 0) steps = 1; // Ensure at least one step
for (int speed = 0; speed <= targetSpeed; speed += 5) {
motorControl(speed, true);
delay(rampTime / steps); // Distribute ramp evenly over total time
}
}
// Usage: ramp to 200/255 speed over 2 seconds
softStart(200, 2000);What to observe: Ammeter shows gradual current increase. No sudden voltage drops on power rail. ESP32 doesn’t reset from brownout.
Scenario: Maintain precise 100 RPM motor speed despite varying loads (fan blades encountering air resistance).
Components needed: Motor + encoder (generates pulses as shaft rotates) + L298N driver
Approach: PID controller compares actual RPM (from encoder) vs target RPM, continuously adjusts PWM to minimize error.
// Simplified PID loop
error = targetRPM - measuredRPM;
integral += error;
derivative = error - lastError;
pwmOutput = Kp * error + Ki * integral + Kd * derivative;
motorControl(pwmOutput, true);
lastError = error;Tuning (Ziegler-Nichols method): 1. Set Ki=0, Kd=0. Start with Kp=2 2. Gradually increase Kp until motor speed oscillates consistently (swings back and forth around setpoint) 3. Reduce Kp by 50% (this is Ku, the “ultimate gain”) 4. Add Ki (start with Kp/2) to eliminate steady-state error 5. Add Kd (start with Kp/8) only if oscillations persist
Safety: Test with motor unloaded first. Monitor current to prevent stall damage.
Result: Motor maintains 100 ±2 RPM even as load changes, vs ±20 RPM with open-loop PWM control.
Scenario: You are designing a smart ceiling fan controller using an ESP32 and a 12V DC motor. The motor runs at 3000 RPM at full voltage and you need 5 discrete speed settings: Off, Low (600 RPM), Medium (1200 RPM), High (1800 RPM), and Max (3000 RPM).
Given:
Steps:
Result: PWM values for 5-speed fan controller: 0 (Off), 64 (Low, adjusted), 102 (Medium), 153 (High), 255 (Max).
Interactive Calculator:
Scenario: You need to select a DC motor for a small package sorting conveyor. The conveyor must move packages weighing up to 2 kg at 0.5 m/s using a 50mm diameter drive roller.
Given:
Steps:
Result: Select a 24V DC motor (6000 RPM, 15 mNm) with 31:1 planetary gearbox.
Interactive Calculator:
Scenario: You are designing an IoT-controlled ball valve for a smart irrigation system. The valve is a 1-inch brass ball valve that requires 90 degree rotation to fully open or close. The system operates on 12V DC from a solar-charged battery and must complete valve actuation within 5 seconds.
Goal: Select and size an appropriate motor and gearbox combination.
Ball valve torque specifications (from valve datasheet):
Design margin: Apply 1.5× safety factor: T_required = 2.5 Nm × 1.5 = 3.75 Nm
Angular displacement: 90 degrees = 0.25 revolutions
Required speed: omega_output = 0.25 rev / 5 s = 0.05 rev/s = 3 RPM
Option: DC Gearmotor (JGB37-520 12V)
| Parameter | JGB37-520 12V | Requirement | Status |
|---|---|---|---|
| Voltage | 12V DC | 12V DC | Pass |
| No-load speed | 10 RPM | 3 RPM | Pass (margin) |
| Rated torque | 5 Nm | 3.75 Nm | Pass |
| Stall torque | 15 Nm | - | Pass (safety) |
| No-load current | 80 mA | - | OK |
| Rated current | 400 mA | - | OK |
| Gear ratio | 1:488 | - | - |
| Cost | $12 | - | Budget |
Selected: JGB37-520 12V DC gearmotor with L298N driver
Key decisions:
Interactive Challenges:
Brushless DC (BLDC) motors have become the preferred actuator for high-performance IoT applications including drones, robotic arms, electric vehicles, and industrial automation.
Six-Step (Trapezoidal) Commutation:
The simplest control method energizes two phases at a time:
| Step | Hall Sensors (H1 H2 H3) | Active Phases | Current Direction |
|---|---|---|---|
| 1 | 1 0 1 | A+, B- | A to B |
| 2 | 0 0 1 | A+, C- | A to C |
| 3 | 0 1 1 | B+, C- | B to C |
| 4 | 0 1 0 | B+, A- | B to A |
| 5 | 1 1 0 | C+, A- | C to A |
| 6 | 1 0 0 | C+, B- | C to B |
Advantages: Simple implementation, low computational requirements
Disadvantages: Torque ripple (up to 14%), acoustic noise
Sinusoidal Commutation:
Applies continuously varying current to each phase for smoother operation:
Field-Oriented Control (FOC):
The most advanced control method for maximum efficiency and smooth operation.
Recommended MCUs for IoT BLDC:
DC motors provide efficient continuous rotation controlled by PWM duty cycle for speed and H-bridge circuits for direction. For applications requiring precise speed regulation, a PID controller with encoder feedback creates a closed-loop system that automatically compensates for load variations. When selecting PWM frequency, choose 20 kHz for silent operation in consumer products or 1-5 kHz for maximum efficiency in industrial applications.
“Wheeee!” shouted DC Danny the Motor, spinning faster and faster. “Max, make me go even faster!”
Max the Microcontroller laughed. “I can’t just give you full power all at once, Danny! I use something called PWM – I flick your power switch on and off really, really fast. The longer I keep it ON, the faster you spin!”
“That’s like turning a light switch on and off super quickly?” asked Lila the LED.
“Exactly!” said Max. “If I keep it ON half the time, Danny spins at half speed. If I keep it ON 75% of the time, he goes at three-quarter speed. It happens so fast that Danny thinks he’s getting a smooth, steady push!”
“But what if I want to go backwards?” asked Danny.
“That’s where my H-bridge friend comes in!” said Max. “Think of it like a figure-eight track for electricity. By switching which path the electricity takes, you spin in reverse!”
Sammy the Sensor was watching Danny’s speed with his encoder. “I count every little tick as Danny spins. If he slows down because something is hard to push, I tell Max, and Max gives Danny more power. Teamwork!”
Bella the Battery reminded everyone, “Just remember – Danny drinks a LOT of my juice, so use only as much speed as you really need!”
| Concept | Relates To | Connection Type |
|---|---|---|
| PWM Speed Control | PWM Control Chapter | Duty cycle determines average motor voltage |
| H-Bridge Operation | Electronics Fundamentals | Four transistors enable bidirectional current flow |
| PID Control | Sensor Feedback | Encoder + PID maintains precise speed regulation |
| Motor Drivers | Actuator Safety | Flyback diodes prevent inductive voltage spikes |
A typical small DC motor draws 100-500 mA; GPIO pins on ESP32 and Arduino are rated for 12-40 mA maximum. Directly connecting a motor to a GPIO pin permanently damages the microcontroller’s output driver within seconds. Always use a transistor, MOSFET, or H-bridge driver IC between GPIO and the motor.
When a transistor turns off a DC motor, the motor’s inductance generates a voltage spike (back-EMF) that can reach 10-50 V above the supply rail. Without a flyback diode across the motor terminals (cathode to positive supply), this spike punctures the transistor’s drain-source junction. Always add a fast recovery diode (1N4007 or Schottky) rated for the motor supply voltage.
PWM frequencies below 20 kHz produce audible tones from motor coil vibration (the coils mechanically vibrate at the PWM frequency). Set motor PWM frequency above 20 kHz (beyond human hearing range) to eliminate this noise. ESP32 can generate 20-40 kHz PWM; Arduino hardware timers may need configuration to reach these frequencies.
DC motors draw 3-10x their rated running current for the first few hundred milliseconds after power application. This startup surge can exceed driver IC peak current ratings or cause power supply voltage sag, triggering microcontroller brownout resets. Add current limiting in firmware (ramp PWM from 0 to operating duty cycle over 100-500 ms) to control startup current.
